Cryo-PC PMF24R 24+2 PoE Switch,24 100Mbps PoE port, 2 Gigabit combo, 440W Internal power, af/at Standard

CPC-PMF24R
$349.00 Excl. tax
  • Availability: In stock (14)

Product description

  • Brand:Cryo-PC
  • Article number:CPC-PMF24R
  • Availability: In stock (14)

Cryo-PC PMF24R 24+2 PoE SwitchThe 24 -Port unmanaged PoE Switch with 24 100Mbps RJ45 PoE ports,2 Gigabit combo, model CPC-PMF24R, reduces equipment and installation costs by delivering data and power over existing Ethernet cables (CAT5 cable)to Power over Ethernet (PoE) enabled devices such as Access Points and IP Cameras.

Boost office efficiency and reduce network congestion with a total switching capacity of 8.8Gbps. LED indicators display device status for easy power management and troubleshooting. An internal power supply reduces clutter and delivers 15.4 Watts to each PoE port. A convenient on/off button is located on the back of the switch. Non-PoE devices can connect to the switch-auto-sensing PoE technology cuts power to non-PoE connected devices. Use PoE Splitter with the Cryo-PC PMF24R to install non-PoE devices in remote locations.



Tehcnical Specifications Model: CPC-PMF24R Network Standards: IEE802.3 10BASE-T, IEEE802.3u 100BASE-TX, IEE802.3ab 1000BASE-T, IEE802.3z 1000BASE-X, IEE802.3x Flow Control, IEE802.3af Power over Ethernet Network Ports: 10/100Mbps 24 PoE RJ45 ports (port 1-port 24); 10/100/1000Mbps 2 Gigabit combo ports MDI/MDIX adaptive (port 25-port 26) Switch Performance: Bandwidth: 52Gbps (non-blocking); MAC address capacity: 8KLED Indicator: Power, PoE, 1000M Link/Activity, 100M Link/Activity Power: PoE power: 400W (PoE port 1-port 24); Max Power: 400W; Single port max 30W Operating Temperature: 0°C-50°C (32°F-104°F) Storing Temperature: -20°C-70°C (-4°F-158°F)

Operating Humidity: 10%-90% (Non-condensing) Storing Humidity: 5%-95% (Non-condensing) Dimensions: 440 x 290 x 44mm / 17.32 x 11.42 x 1.73in Weight: 5 kg / 11.02 lbs

Certifications: CE/FCC/RoHS

Warranty: 1 Year

In the Box: CPC-PMF24R, 1U rackmount brackets, 3ft power cable, user guide
