EVGA Supernova 850 P2, 80+ Platinum 850W, Fully Modular, EVGA ECO Mode, 10 Year Warranty, Includes Free Power On Self Tester, Power Supply 220-P2-0850-X1

Product description

• Brand:EVGA
• Article number:PS-220P20850X1
• Availability: In stock (2)

EVGA Supernova 850 P2, 80+ Platinum 850W, Fully Modular, EVGA ECO Mode, 10 Year Warranty, Includes Free Power On Self Tester, Power Supply 220-P2-0850-X1

CABLE LENGTH
ATX Cable 1x 600mm (m)
EPS Cable 2x 700mm (m)
PCIe Cable 2x 700mm, 850mm (m) 2x 700mm (m)
SATA Cable 2x 550mm, 650mm, 750mm (m) 1x 550mm, 650mm, 750mm, 850mm (m)
Four-Pin Peripheral Cable 1x 550mm, 650mm, 750mm, 850mm (m)
Floppy Adapter 1x 100mm
AC Power 1x 1500mm (m)
Modular Cable Type Full
CONNECTOR QUANTITY
24 Pin ATX 1x
EPS (CPU) 2x 8pin (4+4)
PCIe 4x 8pin (6+2), 2x 6pin
SATA 10x
Four-Pin Peripheral 4x
Floppy 1x
POWER SPECS
AC Input 100 - 240 VAC, 10A, 50 - 60 Hz
Rail +3.3V +5V +12V +5Vsb -12V
Max Output 20A 20A 70.8A 2.5A 0.5A
849.6W
100W 849.6W 12.5W 6W
Total 850W @ +50C
ADDITIONAL DETAILS
Operating Temperature 0° to 50° C
Japanese Capacitors 100%
ECO Mode Yes
MTBF 100,000 Hours
Net Weight 7 lbs
Size 85mm (H) x 150mm (W) x 165mm (L)
Approvals TUV, CB, CE, FCC, RCM, cTUVus, BSMI, CCC, WEEE, RoHS
Compliance with ErP Lot 6 2013 Requirement
Fan Size / Bearing 140mm Double Ball Bearing
